手板在相關技術領域，又稱“樣板”、“打樣件”、“首模樣品”、“模擬樣品”、“仿制樣品”、“比照樣品”、“放大或縮小樣品”、“替代材料樣品”等等。下面小編來講講手板模型的分類、作用以及作用的相關內容吧。

In relevant technical fields, the prototype is also called "sample", "sample making", "first model sample", "simulation sample", "imitation sample", "reference sample", "enlarged or reduced sample", "substitute material sample", etc. Let's talk about the classification, functions and relevant contents of the prototype.

手板模型通常分為：

Prototype models are generally divided into:

1．外形手板；2．結構功能手板；3．真空注型。

1. Outline plan; 2. Structure function manual; 3. Vacuum injection.

手板按照制作的手段分：

Handboards are divided into:

1．CNC手板：主要是用加工生產出來的手板，優點體現在它能非常準確的反映圖紙所表達信息，而且CNC手板表面質量高，尤其在其完成表面噴涂和絲印后，甚比開模具后生產出來的產品還要光彩照人。因此，CNC手板制造愈來愈成為手板制造業的主流。

1. CNC prototype: It is mainly a prototype produced by the machining center. Its advantages are that it can accurately reflect the information expressed in the drawings, and the surface quality of CNC prototype is high, especially after the completion of surface spraying and silk screen printing. It is even more brilliant than the products produced after the mold is opened. Therefore, CNC prototype manufacturing has increasingly become the mainstream of the prototype manufacturing industry.

2:RP手板：主要是用激光快速成型技術生產出來的手板。優點主要表現在它的快速性上，但是它主要是通過堆積技術成型，因而RP手板一般相對粗糙，而且對產品的壁厚有一定要求，比如說壁厚太薄便不能生產，另外受潮容易變形。

2: RP prototype: mainly produced by laser rapid prototyping technology. Its advantages mainly lie in its rapidity, but it is mainly formed by stacking technology. Therefore, RP hand boards are generally relatively rough, and there are certain requirements for the wall thickness of products. For example, if the wall thickness is too thin, it can not be produced, and it is easy to deform due to moisture.

手板制作使用的材料：RTV－2室溫硫化硅橡膠，ABS，PMMA(壓克力）,PC，PP，PA（尼龍），PVC，PVC軟膠，POM，銅，鋁，鋼，電木。

Materials used for the production of the hand board: RTV-2 room temperature vulcanized silicone rubber, ABS, PMMA (acrylic), PC, PP, PA (nylon), PVC, PVC soft rubber, POM, copper, aluminum, steel, and bakelite.

制作手板的作用

Function of making hand board

1．檢驗外觀設計；2．檢驗結構設計；3．參加展覽尋找客戶；4．避免直接開模具的風險性。5．進行小批量產品生產（1~100件）。

1. Inspect the appearance design; 2. Inspect the structural design; 3. Participate in exhibitions to find customers; 4. Avoid the risk of directly opening the mold. 5. Conduct small batch production (1~100 pieces).

手板產品模型制作方法：

Manufacturing method of prototype product model:

1、脫蠟法：

1. Dewaxing method:

先利用石蠟制作一個產品模型，在模型上粘一個石蠟棒（將來的澆注口，簡稱澆注口棒）。再手提“澆注口棒”，在紙盒中用調制好的“石膏漿”澆注，20分鐘后，去掉紙盒放進100度開水鍋中“沸煮”30分鐘，讓蠟全部煮出。撈出后烘干或曬干，這樣，一個模具就“制造成功了”。然后，將加熱熔化的塑料，從澆注口灌滿，冷卻、開模。這樣，一個光潔度大的產品模型就制作完成了。

First, make a product model with paraffin, and stick a paraffin stick on the model (the future pouring mouth, referred to as the pouring mouth stick). Then hold the "pouring mouth stick" and pour the prepared "gypsum slurry" in the paper box. After 20 minutes, remove the paper box and put it into a 100 degree boiling water pot to "boil" for 30 minutes, allowing the wax to boil out completely. After being fished out, it is dried or dried in the sun. In this way, a mold is "successfully manufactured". Then, fill the heated and melted plastic from the pouring port, cool and open the mold. In this way, a product model with large finish is completed.

2、拷貝法：

2. Copy method:

先把自己手均勻涂上一層厚厚的“洗潔凈”，把調治好的“有機硅模具膠”涂到手上，每十分鐘涂一遍共涂三遍。兩個小時后，你就可以脫下一個“厚厚的手板模具”，他的耐溫達300度C。澆注塑料后凝固后，可以脫下模具。一個“手板”的產品模型就成功了！

First, evenly apply a thick layer of "washing and cleaning" on your hands, and apply the cured "silicone mold glue" to your hands. Apply it every ten minutes for three times in total. In two hours, you can take off a "thick hand mold", which has a temperature resistance of 300 ℃. After the plastic is poured and solidified, the mold can be removed. A "prototype" product model is successful!

手板后期處理工藝有：噴油漆，電鍍，激光鐳射，絲印移印，鋁合金陽極氧化。，這一方面還是要多去注意，更多相關內容了解，大家可以來我們網站http://m.csguangliang.com進行咨詢！

The manual post treatment processes include: oil spraying paint, electroplating, laser laser, silk screen printing, aluminum alloy anodizing., In this regard, we should pay more attention. For more information, please visit our website http://m.csguangliang.com Consult!
